Compiling a C program is a bit confusing for newbies since it doesn’t have a central place that you can download “the C compiler” or read the language documentation. Don’t you worry though, there is a language reference, from ISO. But it isn’t free. So, maybe worry a little?

With lack of the central authority and the wide adoption of the language resulted community driven compilers/libraries to emerge. Meaning there is no so-called default compiler but community driven and hugely populer compilers/libraries.

This article tries to address what are make, cmake, clang, gcc or mingw means and how do people use them to write C programs.

Most of the things that are written here also applies to C++ with some minor differences.

Steps and Toolset

C is no different than current programming languages when steps and toolset is considered. But there is a caveat: You need to do some of the steps manually, while other “modern” languages do them for you.

Let’s say we need to compile a basic C program with standard library with operating system support. These are the possible steps required to be done by the programmer:

Give include directory as a flag to compiler
Give target source file to compiler for creating object files
Do these steps for every source file
Give object files to compiler for creating final binary

Actually steps 2 and 4 can be combined. But it is not a sane thing to do and will be explained why, later.

If you don’t want operating system defaults, want to do custom things or don’t have an operating system underneath your program, you may need to follow these steps also:

Write a linker file
Give a custom standard library path to compiler
Write required low level libraries yourself

Please note that, these steps are not necessary if you are not writing low level software.

The Compiler

As I said before, there is no official compiler. 2 of the most popular community driven and open source compilers are called gcc and clang. There are other open source and priprioraty compilers out there but these 2 will be the focus of this article.

They are completly different compilers and developed by completely different teams. But they function the same and used the same for the developer. Examples will be based on gcc simply because I use that as my main C compiler.

They follow the standards developed by international organizations like ISO¹.

For bare-metal targets, you mostly will need another compiler for your target architecture. For example: You want to compile your code to ARM CPU’s without an operating system, arm-none-eabi-gcc is the way to go. It’s basically gcc but for the ARM architecture.

There is another caveat for targetting bare metal environments: Low level stuff (like hardware interrupt handling) highly dependent on the compiler it’s developed with. That’s because C standard mostly independent from CPU architecture and compilers implement those architecture specific features however they like. If in doubt, just grab the same compiler used in your project.

The Code

There are 2 kind of source files: .c and .h.

The files with .c suffix includes the main code and compiler compiles those files to a binary format. These binary files defines code that is going to be executed, mostly.

.h files (also called as headers) in the other hand, can also include definitions. But they are mostly used for including declarations. Those declarations gets passed to .c files and they won’t be putted in binaries; They tell there should be some executable code matching that definition, somewhere in the other binaries, to the compiler.

An example to this: Let’s assume we need to create a program that accepts a number as an input and outputs 2 times of itself. This is a very basic example that can only be written with one .c file. But for the sake of this example, let’s divide it into 3 pieces:

main.c: Calls everything
input.c: Takes the input from user
calculate.c: Calculates and prints the output

This little example’s source code will roughly look like this:

main.c:

int main()
{
    int input = get_input();
    calculate(input);

    return 0;
}

input.c:

#include <stdio.h>

int get_input()
{
   int input;
   scanf("%d", &input);
   return input;
}

calculate.c:

#include <stdio.h>

void calculate(int input)
{
    printf("%d * 2: %d\n", input, input * 2);
}

If we give all of the these files to compiler, some compilers will produce a binary. This is called implicit declaration and is not legal² in C standard. GCC is some of the compilers that produces an output, with a warning:

$ gcc main.c input.c calculate.c
main.c: In function ‘main’:
main.c:3:17: warning: implicit declaration of function ‘get_input’ [-Wimplicit-function-declaration]
    3 |     int input = get_input();
      |                 ^~~~~~~~~
main.c:4:5: warning: implicit declaration of function ‘calculate’ [-Wimplicit-function-declaration]
    4 |     calculate(input);
      |     ^~~~~~~~~

You can link completely independent C sources into one binary. Because of that, compiler wants to know if there is a function that you are trying to call. If there isn’t, compilation will fail.

This is where header files comes to stage. When we create a .c file, we better off put public functions declarations to an .h file. After that, compiler won’t complain and compile just fine. This also helps other developers to use your code as a library. So, let’s add these 2 header files to our little project:

input.h:

int get_input();

calculate.h:

void calculate(int input);

We didn’t create the main.h file because no other .c file uses any function or other things in main.c.

Finally, we need to include these 2 headers to where they are called:

main.c:

#include "input.h"
#include "calculate.h"

int main()
{
    int input = get_input();
    calculate(input);

    return 0;
}

There are no warnings anymore and is compilant with the standard.

In a real world scenario, you might see a weird stuff in header files, that looks like #ifndef _INPUT_H. This is a weird workaround for the language design. They are called include guards and they are a must, most of the time.

How To Compile Source Files?

If we take the last example, our project contains these files:

├── calculate.c
├── calculate.h
├── input.c
├── input.h
└── main.c

Assuming our C compiler is gcc, we can compile everything with one of these commands:

gcc calculate.c input.c main.c
# Or
gcc *.c

Either way, compile times will get longer as the project gets bigger. And there is a huge problem comes with it: We are compiling every source file in each iteration even we changed only one source file.

To solve this issue, we can compile every .c file separately and link them later. if we changed the contents of a file, we won’t need to compile rest of the program and our compilation times will get lower dramatically. We can do this by using these commands:

gcc -c calculate.c
gcc -c input.c
gcc -c main.c
gcc *.o

The -c flag will compile the source files but does not link to an executable (creates a .o file, a.k.a. object files). Linking all the .o files together, is way faster than compiling everything over and over. But let’s say we are working on a bigger project with 100’s or 1000’s of source files that are scattered in sub-directories. Are we really going to find all the source files and compile one by one? Maybe writing a script would do the trick, eh? But a simple script won’t keep track of the changed files and will compile everything again. And there are so many other compilation specific stuff that we don’t want to keep track of.

Any easy way to deal with this? Yes, let’s invent multiple different build systems!

Build Systems

Lazy people who don’t want to deal with this compilation turmoil, created build systems. Again, there is no standard, so every lazy person decided that previous build system sucked and created a new one. So we have a handful of build systems now. Some of them are:

Make
Cmake
Autotools
Ninja
Meson
Other IDE specific ones (like Code::Blocks)

Probably the most popular one is make. And I can say, it is a pain in the ass to write an useful Makefile (which is the make “recipe”). There is a high chance to spend a day in order to write a Makefile after a C project gets bigger.

There are higher level build system that creates Makefile’s: cmake and autotools are the 2 examples of this. But don’t think they are easier to use or easier to learn. They are just one step further from make, The same story can be applied to rest, I assume.

The point of these build systems is: Let the developer worry about the code and not on compiling it. And I have to say, they fail. I mean, look at Rust, cargo just solves so many unnecessary issues that C introduces. I don’t have to deal with third party library compilation, compile time definitions or header files. I just run cargo in the root directory and cargo will just compile stuff. In order to have something like this in C world, build systems must force some project structure rules to it’s users. Either no one ever wanted to create a tool like this or C people hate to be told what to do.

Maybe we need a one last build system built upon the mistakes of it’s predecessors, that solves all of our problems and agonies?

Relevant xkcd: Standards https://xkcd.com/927/

Stories

There are some stories I want to tell about compiling C programs:

Installing GCC in Windows

Back in the day, I tried to install gcc to my friend’s Windows laptop, needless to say it was painful. Firstly, gcc is not natively supported on Windows. So some other guys ported gcc to Windows and called it MinGW³. If you search it on the internet, you will most likely see SourceForge links at the top of the page. What? I get that there was no official C website but this was too much. At least put the binaries in Github or something. When I first visited that site, I thought it was a virus site and left. After some searching, I gave up and downloaded it from there. Luckily, it was not a virus. But the torture was not yet to over.

I won’t tell more about this. If you are a freshman, have fun spending the rest of your day figuring out how to install the thing properly. Fortunately, there are some better ways to install a C compiler in Windows today, through WSL. But you need to know your way around Linux to use this.

Confusion Between Build Systems and Compiler

If you are using some old LTS Linux distro, like Ubuntu 20.04, your compiler probably has an old version and won’t have support for new standards.

One of my colleague (had little to none experience on C/C++ before her job there) needed to compile an open source C++ project which uses cmake as the build system. The compilation was failing and she had no clue why. When I looked at it, I saw that project included a C++ 20 standard library header and her compiler (g++ on Ubuntu 20.04) wasn’t supporting that standard. So, she tried to upgrade cmake, as she thought it was the compiler naturally.

This made me realize again that compiling a C/C++ program is unnecessarily complex and cumbersome. She was a software engineer and she compiled and used some other projects in different languages. But with C/C++, it was another story. So many people think C is an ancient language that needs to die, and they don’t even know this build system hell hole.

Conclusion

We can say all the build systems for every language have their own problems and quirks. But with C, there is little to none official documentation and smaller communities on newbie friendly sites, like YouTube, is a problem for outsiders and newbies.

C is everywhere and the whole world probably collapse without it. If we need to use those important software, first we need to compile them. Fortunately, not all people nor developers need to compile a C program. For those who need to compile one or worse write a compiling instruction, good luck.
